T2001通孔回流系列 2mm间距

产品详情

技术参数

Product Parameter

Circuits (maximum)	2	Color - Resin	Black
Flammability?	94V-0	Gender	Receptacle
Glow-Wire Capable	Glow-Wire Capable	Keying to Mating Part	None
Lock to Mating Part	Yes	Material - Resin	Nylon
Packaging Type	Bag	Pitch - Mating Interface	3.00mm
Temperature Range - Operating	-40° to +105°C	Contact resistance	≥1000MΩ
Rated voltage	250V AC DC	Rated current	2A AC DC
Withstand Voltage	1000V AC/minute	Plating	Tin

Product Compliance

EU RoHS Directive 2011/65/EU

Compliant

EU ELV Directive 2000/53/EC

Compliant

China RoHS 2 Directive MIIT Order No 32, 2016

No Restricted Materials Above Threshold

EU REACH Regulation (EC) No. 1907/2006

Does not contain REACH SVHC

Disclaimer

This information is provided based on reasonable inquiry of our suppliers and represents our current actual knowledge based on the information they provided. This information is subject to change. The part numbers that CJT has identified as EU RoHS compliant have a maximum concentration of 0.1% by weight in homogenous materials for lead, hexavalent chromium, mercury, PBB, PBDE, DBP, BBP, DEHP, DIBP, and 0.01% for cadmium, or qualify for an exemption to these limits as defined in the Annexes of Directive 2011/65/EU (RoHS2). Finished electrical and electronic equipment products will be CE marked as required by Directive 2011/65/EU. Components may not be CE marked. Additionally, the part numbers that CJT has identified as EU ELV compliant have a maximum concentration of 0.1% by weight in homogenous materials for lead, hexavalent chromium, and mercury, and 0.01% for cadmium, or qualify for an exemption to these limits as defined in the Annexes of Directive 2000/53/EC (ELV). Regarding the REACH Regulation, the information CJT provides on SVHC in articles for this part number is based on the latest European Chemicals Agency (ECHA) ‘Guidance on requirements for substances in articles’ posted at this URL: https://echa.europa.eu/guidance-documents/guidance-on-reach

Product Application

通常使用在混合型电子组装类型的PCB板上，重要由于元件地位比力紧凑，

思考到元件尺寸大幼，数量蹬装响比力大的PCB板，双面焊接的PCB板，

这些使用通孔回流焊接，可解决焊接需要。

使用在例如：？仄鳌⒐嘁艋⑹蟊辍⒓獭⒌缡踊⒌绲缟取⒌缭蠢嗟炔稰CB上
